oil purifier/oil filtrating/oil purification

Price:	1.0~12000.0 USD
Payment Terms:	T/T,L/C
Special Groups:	double-stage high vacuum transformer oil (4)
Place of Origin:	Chongqing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ZYD-10 Oil Purifier

Production Capacity: 100 sets/month

Delivery Date: 10 days

Certification: CE

Color: yellow,blue,green

Means of Transport: Ocean,Land,Air

Packing: wooden case

Type: Vacuum Oil Purifier

Brand Name: TOP Oil Purifier

Low Cost Vacuum transformer oil purification system with CE,vacuum system,reduce downtime and running costs,filtering

Low Cost Vacuum transformer oil purification system with CE,vacuum system,reduce downtime and running costs,filtering

Chongqing Top Oil Purifier Manufacture Co.,Ltd systems:

Cleanse fuel, oil, hydraulic and other fluids effectively
Reduce damage to machines from contaminated fluids
Reduce downtime and running costs
Lower harmful emissions
Extend life of OEM filters
Extend component life.

Where this Oil Purification used?

This Double-stage Continuous On-Site Transformer Oil Treatment Plant Is Applied for Purifying the Insulation Oil in all kinds of large Power equipment, which Voltage larger than 110kv, altitude larger than 500M.

Features:

1. Double-stage High Vacuum dehydration and degassing and removing impurities from the used transformer oil.
2. Eliminate acidity, sludge, free carbon, discoloration elements, and other soluble matters in the oil, which decays the transformer.
3. It can vacuum filling oil to transformers, and it can vacuum dry transformers and on-line operation with transformer.
4. The standard ZYD system is designed for purifying and filtering oils in workshops, in storage tanks or directly in transformers (energized or de-energized transformers).

5. Stainless steel material made for the machine body, which can make prolong the machine's life time more than 10 years.

The oil technical data after treatment:
1. Gas content is less than 0.1%
2. Impurity size is less than 1μm without free carbon

3. Water content is less than 3 part per million
3. Oil dielectric strength (breakdown voltage) is more than 75KV
4. Acidity value is less than 0.01 mg KOH/g
5. Dielectric loss factors at 90°C is less than 0.001

Advantages:

It's a new-type of high effective vacuum oil purifier with the duplex 3D stereo-evaporation technology and G technology. Also it adopts the technology, which remove the impuritiesthrough double FH trapezoidal network and absorbing by high polymer without the mechanical power. So it's five or eight times as effective as the common vacuum oil purifiers, the consumption of energy is least and it's doesn't need other wearing materials.

Technical Data

Parameters		Unit	ZYD-30	ZYD-50	ZYD-100	ZYD-150	ZYD-200	ZYD-250	ZYD-300
Flow		L/min	30	50	100	150	200	250	300
Working vacuum		MPa	0.08 ~ 0.099
Working Pressure		MPa	≤0.3
Breakdown Voltage		KV	≥65
Water Content		PPM	≤5
Gas Content		%	≤0.1
Impurity Size		μ	≤5
TemperatureRange		°C	20 ~ 80
Power			Three Phase 50HZ380V(as per the customer's requirements)
Working Noise		dB(A)	75	75	75	80	80	80	80
Heating Power		kW	30	30	45	60	75	90	120
Total Power		kW	35.5	37.5	52.5	71.4	86.5	102.5	135
Inlet/Outlet		mm	φ25	φ32	φ42	φ50	φ50	φ60	φ60
Weight		kg	600	800	1050	1400	1800	2000	2200
Overall	Length	mm	1050	1100	1200	1450	1600	1800	1900
	Width	mm	750	800	950	950	1100	1200	1200
	Height	mm	1350	1400	1500	1650	1800	1900	1900
